Customize Versatile 50T 6-Cylinder Cold Press Machine: Ideal for Medical Doors Pickleball Pads Laminated Wood
Description
This double row 6-cylinder cold press machine is a heavy-duty hydraulic cold press equipment specially designed for large-scale, high standard, and medium to large batch plate pressing scenarios. It directly targets the pain points of traditional single row/few cylinder cold press machines, such as uneven pressure, large plate pressing hollowing, deformation during heavy-duty operation, and insufficient pressure holding accuracy. It is the core main production equipment for door and plate processing.
Feature
1,Superior production capacity
Despite its compact size, this mini cold press machine performs equally well in terms of production capacity, achieving efficient production through an optimized hydraulic system and rapid circulation design. Adopting a bidirectional oil circuit design, it has fast oil output and return, faster mechanical action, and greatly shortens the compression cycle.
2,Integrated Safety and Protection
The double row symmetrical 6-cylinder synchronous drive design completely breaks the industry common problem of "sufficient pressure in the middle and weak pressure at the edges and corners" in traditional single row cold press machines. The pressure deviation of the full pressure plate is controlled within 1%. Whether it is a whole wooden door, large-sized ship board, thin sound-absorbing board, or Pick racket sheet, it can achieve uniform bonding in the entire area, eliminating problems such as hollowing, layering, edge curling, and insufficient pressing from the root. The product qualification rate is steadily improved, greatly reducing raw material loss and rework costs, and directly increasing the profit margin of individual products.
3,Wide-Ranging Application Versatility
The double row 6-cylinder cold press machine has a wide range of applications in the fields of building decoration materials, sports equipment, and special sheet metal processing due to its super strong pressure output, uniform pressure distribution, and spacious worktable. In terms of door manufacturing, the equipment is suitable for large-scale pressing production of various wooden doors and medical doors. The double row six cylinder design ensures that even large-sized door panels can withstand uniform force, and the surface of the door leaf is free of bubbles and glue, meeting the strict requirements of medical places for door flatness. In the field of basic board processing, equipment can efficiently complete multi-layer lamination of plywood, with strong and stable pressure, ensuring that the board layers are firmly bonded without delamination. In the manufacturing of metal composite panels, it is suitable for the compression molding of corrugated composite panels, ensuring a strong bond between the corrugated core material and the panel through uniform pressure distribution.
4,Easy maintenance and technical support
It is necessary to check daily whether the fastening screws of each oil cylinder flange and cylinder rod are loose and tighten them in a timely manner, observe whether there is any leakage at each oil circuit interface, and promptly deal with any leakage found. In terms of electrical systems, the usage status of each component and travel limit switch inside the electrical control box should be checked monthly.
Specification
|
Max pressuer
|
50 T |
|
Work platen size
|
4000*2000mm |
| Oil cylinder specification |
100mm * 6pcs |
| Motor power |
5.5kw |
| Workd effctively |
1000mm /1300mm / 1500mm / customizable |
| Overall dimensions (Standard Model) |
4500*2000*3700mm |
| Weight (Standard model-about) |
6000 kg |
Advantage
1,Two In-House Factories = Better Prices, Faster Delivery
We own two independent R&D and manufacturing facilities. No middlemen. No markups. You buy straight from the source, with full control over production speed and costs.
2,More than 30 senior engineers, Custom-Built for You
Our 30-person R&D team designs machines around your actual production needs, floor space, and budget. Tell us what you're making—we'll build exactly what you need.
3,CE & ISO 9001 Certified, Global-Ready
Every machine meets EU CE safety standards and ISO 9001 quality requirements. That means full compliance with international electrical, mechanical, and safety regulations—ready to plug and play anywhere in the world.
4,More than 50 countries, 1000+ Projects, Experienced in design and manufacturing
We've shipped to over 50 countries and completed 1,000+ custom designs. Our equipment is engineered for long-term, heavy-duty use—proven in real factories worldwide.
Service Support
- Warranty: 1 year
- Packaging: Film with foam
- 24-hour customer service hotline, respond to repair needs within 48 hours.
- Free video training for operators and provision of process guidance manuals.
- Lifetime technical support and software upgrade services.
Scope of Application
Product Display
Production workshop actual shooting
Product details
Company Introduction
Corporate Advantages
Visitors and Communication
Production level and manufacturing process
Exhibition and Exchange
Packaging and Logistics
Certificates and Honors
