Rubber vulcanization hot press machine for producing fitness mats inflatable beds and yoga mats
Description
The rubber vulcanization hot press machine is a specialized hot press equipment designed for efficient vulcanization molding of rubber products. Its core structure consists of a hydraulic system, a heating platform, an electrical control system, and a high-strength body. The equipment applies precise and controllable pressure and temperature to rubber materials, promoting cross-linking reactions of rubber molecules and ultimately forming rubber products with specific physical and mechanical properties.
Feature
1,Superior production capacity
Intelligent temperature control system combined with fast heating design, the heating speed of the hot press plate is fast, without the need for long preheating waiting; The vulcanization curve can be accurately set according to the rubber formula, maximizing the reduction of vulcanization time while ensuring product performance.
2,Integrated Safety and Protection
This machine is equipped with multiple protection mechanisms to ensure the safety of workers and production equipment from multiple aspects. Automatic detection of system pressure and automatic warning of overpressure to protect hydraulic components. The hot pressing temperature protection knob automatically shuts down when the set temperature is exceeded and the power is cut off. Red prominent emergency brake button, one click brake in special circumstances.
3,Wide-Ranging Application Versatility
Rubber vulcanization hot press machine has a wide range of applications in the field of rubber product processing due to its wide material adaptability and excellent molding performance. In terms of sports and fitness equipment, the equipment is suitable for vulcanization molding of yoga mats, fitness mats, protective air cushions and other products, ensuring uniform density and excellent elasticity through uniform heating and high pressure. In the field of mattress manufacturing, equipment can be used for the production of inflatable mattresses, sponge mattresses, memory foam pads, leisure mattresses and other products, meeting the comfort and durability requirements of the home industry. In the field of medical rehabilitation, the equipment is suitable for vulcanization molding of rehabilitation pads, seat cushions, medical silicone products, and other products. In the field of outdoor leisure, equipment can be used for mass production of inflatable beds, protective air cushions, and other products. In the field of new energy, equipment can be used for the manufacturing of battery seals, thermal conductive silicone pads, and energy storage equipment components.
4,Easy maintenance and technical support
Clean the residual adhesive and dirt on the surface of the hot plate; Keep the equipment and surrounding environment clean. Check and lubricate all sliding components such as guide posts and guide sleeves. Detailed testing of all safety circuits, relays, and emergency stop functions. The whole machine adopts a modular split design, with independent layout of hydraulic system, heating system, electrical system, and numerical control system. Fault diagnosis and positioning are fast and accurate, and single module and single-layer workstation maintenance do not require the whole machine to stop, minimizing the impact of downtime on order delivery.
Specification
| Max pressuer |
100 T |
| Work platen size |
2200*1650mm |
| Systm pressure |
20 mpa |
| Max.platen opening |
400mm |
| Maximum temperature |
180℃ |
| Working level |
1-layer |
| Oil cylinder specification |
125mm*90mm * 4pcs |
| Hydraulic pump power |
11kw |
| Heating pipe power |
72kw |
| Overall dimensions |
6275*2940*2658mm |
| Weight (about) |
11000 kg |
Advantage
1,Two In-House Factories = Better Prices, Faster Delivery
We own two independent R&D and manufacturing facilities. No middlemen. No markups. You buy straight from the source, with full control over production speed and costs.
2,More than 30 senior engineers, Custom-Built for You
Our 30-person R&D team designs machines around your actual production needs, floor space, and budget. Tell us what you're making—we'll build exactly what you need.
3,CE & ISO 9001 Certified, Global-Ready
Every machine meets EU CE safety standards and ISO 9001 quality requirements. That means full compliance with international electrical, mechanical, and safety regulations—ready to plug and play anywhere in the world.
4,More than 50 countries, 1000+ Projects, Experienced in design and manufacturing
We've shipped to over 50 countries and completed 1,000+ custom designs. Our equipment is engineered for long-term, heavy-duty use—proven in real factories worldwide.
Service Support
- Warranty: 1 year
- Packaging: Film with foam
- 24-hour customer service hotline, respond to repair needs within 48 hours.
- Free video training for operators and provision of process guidance manuals.
- Lifetime technical support and software upgrade services.
